• Country
• Japan

• Manufacturer / Brand
• Hitachi Ltd.; Tokyo

• Year
• 1979

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 251171

• • alternative name: Hitachi Sales Corp. of America

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 24

• Semiconductors

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220; 240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Amplifier HA-3500 - Hitachi Ltd.; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 435 x 110 x 275 mm / 17.1 x 4.3 x 10.8 inch

• Notes

• Hitachi Stereo Amplifier Model HA-3500.
  2x 30 Watts into 8 Ohms, 20 - 20000 Hz, 0,05%
  Power level meters foroutput power readout
  Bass- & Treble-Control, Loudness, Subsonic Filter
  LED program source indicators
  Phono IN, Tuner IN, Tape1,2
  Power Consumption 160 Watts.


• Net weight (2.2 lb = 1 kg)
• 6 kg / 13 lb 3.5 oz (13.216 lb)

• Source of data
• -- Original-techn. papers.

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
