Stereo Cassette Tape Deck D-580

Hitachi Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1978
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 284941
    • alternative name: Hitachi Sales Corp. of America

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 28
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Cassette Tape Deck D-580 - Hitachi Ltd.; Tokyo
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 435 x 143 x 256 mm / 17.1 x 5.6 x 10.1 inch
  • Notes

  • Hitachi Frontloading Stereo Cassette Tape Deck Model D-580.
    2-head, single compact cassette deck, 4-track, 2-channel stereo
    Tape Speed: 4.75 cm/s
    Heads: 1 x record/playback, 1 x erase
    Motor: 1 x DC, 1 x DC servo
    Tape Type: type I, FeCr, CrO2
    Noise Reduction: Dolby B
    Frequency Response: 20Hz to 18kHz (CrO2 tape)
    Signal to Noise Ratio: 62dB (dolby B)
    Wow and Flutter: 0.04%
    Total Harmonic Distortion: 1.5%
    Input: 80mV (line), 0.38mV (mic)
    Output: 0.5V (line)
    Bias Adjust
    3-Digit analog Tape Counter
    Auto Rewind
    Power Consumption 30 Watts

    Semiconductors:
    5x IC's, 28x transistors, 27x diodes, 5x LED's

  • Net weight (2.2 lb = 1 kg)
  • 6.9 kg / 15 lb 3.2 oz (15.198 lb)
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
