- Country
- United States of America (USA)
- Manufacturer / Brand
- Hoffman Radio Corp.; Los Angeles, CA
- Year
- 1951 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 349317
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6CB6 or 6J6 6J6 6CB6 6CB6 6CB6 6CB6 6AL5 6CB6 6AU6 6AU6 6AU6 6AL5 6SQ7 6K6GT 6AU6 6SN7GT 6BL7GT 6SN7GT 6BG6G 6W4GT 1X2A 5U4G 17BP4
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent or electro-dynamic (moving coil), system not known yet.
- Material
- Wooden case
- from Radiomuseum.org
- Model: 894 185 - Hoffman Radio Corp.; Los
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Hoffman model 894 is a 17” b/w TV with US standard VHF tuner channels 2 thru 13.
Equipped with chassis 185, phono provisions,VHF tuner 99618 or 99619 and picture tube 17BP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 141, folder 7, dated 8-51)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
