• Country
• United States of America (USA)

• Manufacturer / Brand
• Hoffman Radio Corp.; Los Angeles, CA

• Year
• 1948

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 44395

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 23

• Valves / Tubes
• 6BA6 6BE6 6C4 6BA6 6BA6 6AL5 6AT6 6SJ7 6J5GT 6SJ7 6SL7GT 6SL7GT 6U5 6K6GT 6V6GT 6X5GT 6J5 6J5GT 6K6GT 6K6GT 6K6GT 6K6GT 5U4G

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Tuned circuits
• 7 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Other Combination - see Notes

• Power type and voltage
• Alternating Current supply (AC) / 110 - 120 Volt

• Loudspeaker
• Ø 14.5 inch = 36.8 cm

• Power out
• 18 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: C1007 Ch= 132 - Hoffman Radio Corp.; Los

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• AC Operated Combination Phono-Radio-Wire-Recorder,
  AM-FM Superheterodyne Receiver with Loop Antenna

  AM: 535-1650 kc    FM: 88-108 Mc

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 18 = 1949 and before

• Mentioned in
• Guide to Old Radios

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (492-9, Set 54, Folder 9)
