Eight Transistor RP708 Ch= BP-318
Hoffman Radio Corp.; Los Angeles, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hoffman Radio Corp.; Los Angeles, CA
- Year
- 1961 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 328899
- Number of Transistors
- 8
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / AA: 4 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 0.15 W (max.)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Eight Transistor RP708 Ch= BP-318 - Hoffman Radio Corp.; Los
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 127 x 73 x 37 mm / 5 x 2.9 x 1.5 inch
- Notes
-
Slide rule station dial with US Civil Defense marks on the dial. Reverse painting. Volume dial shows numbers through plastic peep-hole. Similar to OP708 model.
Made in Japan
- Author
- Model page created by Ray Albright. See "Data change" for further contributors.
