M4041 Ch= 706
Hoffman Radio Corp.; Los Angeles, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hoffman Radio Corp.; Los Angeles, CA
- Year
- 1958
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 319836
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 30
- Valves / Tubes
- 6BN4 6CG8 6DE6 6DE6 6CB6 6AW8 12BY7A 6U8 6AU6 6AU6 6T8 6AQ5 6CG7 6AQ5 6CG7 6CB5 6AU4GT 1V2 3A3 6BK4A 6AW8 6AW8 6CB6 12BH7A 6BY6 6BY6 12BH7A 5U4GB 5U4GB 21AXP22A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: M4041 Ch= 706 - Hoffman Radio Corp.; Los
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
Hoffman model M4041 is a 21" color TV with US standard VHF tuner channels 2 thru 13. Equipped with chassis 706, VHF tuner 710005 and picture tube 21AXP22A.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 386 Folder 3 dated 1-58)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
