Orgaphon 24 MH
Hohner, Matthias, AG; Trossingen
- Country
- Germany
- Manufacturer / Brand
- Hohner, Matthias, AG; Trossingen
- Year
- 1967 ?
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 129715
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Conflicting model year with tube data.
- The model date contradicts tube dates. [ PCL805 (1968)]
- Number of Transistors
- 8
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 25 cm = 9.8 inch
- Power out
- 20 W (unknown quality)
- Material
- Various materials
- from Radiomuseum.org
- Model: Orgaphon 24 MH - Hohner, Matthias, AG;
- Notes
- 3x BC109, 1x BY250
mit Federhall, getrennt regelbar für jeden Eingang
LS= Breitbandsystem 10", Typ PM245 / 15 Ohm.
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by Willi Ribbe. See "Data change" for further contributors.
