• Country
• Japan

• Manufacturer / Brand
• Holiday; (brand)

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 250301

• Number of Transistors
• 6

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / 1 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: 6 Transistor - Holiday; brand

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 55 x 85 x 25 mm / 2.2 x 3.3 x 1 inch

• Notes

• Linear dial. Tuning range: 53 - 160 kHz.
  Leather case and earphone.

• Net weight (2.2 lb = 1 kg)
• 0.138 kg / 0 lb 4.9 oz (0.304 lb)

• Author
• Model page created by Marc Couque. See "Data change" for further contributors.
