• Country
• United States of America (USA)

• Manufacturer / Brand
• Howard Radio Company; Chicago (IL)

• Year
• 1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 44541

• Number of Tubes
• 11

• Valves / Tubes
• 6K7 6A7 6K7 6K7 6U5 76 6F5 6J5 6V6 6V6 80

• Main principle
• Superhet with RF-stage

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 105-120 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: 400X - Howard Radio Company; Chicago

• Shape
• Console with Push Buttons.

• External source of data
• Ernst Erb

• Circuit diagram reference
• Rider's Perpetual, Volume 10 = 1939 and before

• Other Models

• Here you find 354 models, 152 with images and 214 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Howard Radio Company; Chicago (IL)
