Sussex 620
Howard Radio Pty. Ltd.; Richmond VIC
- Country
- Australia
- Manufacturer / Brand
- Howard Radio Pty. Ltd.; Richmond VIC
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 317620
Howard-aus 620 cabinet rear
Howard-aus 620 model/serial number
Howard-aus 620 chassis front
Howard-aus 620 chassis rear
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 6 AF stage(s)
- Tuned circuits
- 2 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Sussex 620 - Howard Radio Pty. Ltd.;
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 22 x 40.5 x 12 inch / 559 x 1029 x 305 mm
- Notes
-
5-valve, AC-powered Superhet with magic eye tuning indicator.
Advertised as the same as the Model 619 including special sensitivity control plus AVC and Magic Eye.
Some adverts show it as the Sussex 620.
- Mentioned in
- -- Original prospect or advert (The Albury Banner and Wodonga Expess, 12/6/1936, page 3 (Trove Newspapers))
- Literature/Schematics (1)
- Mingay's "Radio Diagram & I.F. Index
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
