310R Record Player
Hudson Electronics, Mt. Vernon, NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hudson Electronics, Mt. Vernon, NY
- Year
- 1953 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 349724
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 2
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Rec.Player+Audio.Amp+LS
- Power type and voltage
- Alternating Current supply (AC) / 60 Cycle, 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- from Radiomuseum.org
- Model: 310R [Record Player] - Hudson Electronics, Mt.
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Hudson model 310R is an AC operated audio amplifier with 3 speed manual record player.
Rating: .42 Amp @ 117 Volts AC.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 190, Folder 5, Date 1-53)
- Author
- Model page created by Rene Chenier. See "Data change" for further contributors.
