- Country
- Germany
- Manufacturer / Brand
- Huth, Signalbau AG, Dr. Erich Franz Huth (Signalbau Huth); Berlin später auch Hannover
- Year
- 1923/1924
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 15024
-
- alternative name: Ges. für Funkentelegraphie mbH
- Brand: Signalbau Huth
- Number of Tubes
- 1
- Valves / Tubes
- Main principle
- TRF without regeneration
- Tuned circuits
- 1 AM circuit(s)
- Power type and voltage
- Storage and/or dry batteries
- Loudspeaker
- - For headphones or amp.
- Material
- TUBES VISIBLE, material not known.
- from Radiomuseum.org
- Model: EL122a - Huth, Signalbau AG, Dr. Erich
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 220 x 90 x 200 mm / 8.7 x 3.5 x 7.9 inch
- Notes
- ist EL129 ohne Rückkopplung; "Zwischenkreisempfänger".
- Net weight (2.2 lb = 1 kg)
- 1.9 kg / 4 lb 3 oz (4.185 lb)
- External source of data
- E. Erb 3-907007-36-0
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Mentioned in
- Funkgeschichte der GFGF (8647)
- Picture reference
- Das Modell ist im «Radiokatalog» (Erb) abgebildet.
