• Country
• Spain

• Manufacturer / Brand
• Iberia Radio, S.A.; Barcelona

• Year
• 1962

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 116897

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• UCH81 UF89 UL84 UY85 UBC41

• Main principle
• Superheterodyne (common); ZF/IF 467 kHz; 2 AF stage(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 110-130 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: B-152 - Iberia Radio, S.A.; Barcelona

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 270 x 164 x 140 mm / 10.6 x 6.5 x 5.5 inch

• Source of data
• - - Data from my own collection

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Juan José Gonzalez-Reguera. See "Data change" for further contributors.
