• Country
• Spain

• Manufacturer / Brand
• Iberia Radio, S.A.; Barcelona

• Year
• 1960 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 112678

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UCC85 UCH81 UF89 UABC80 UL84 UY85

• Main principle
• Superheterodyne (common); ZF/IF 467/10700 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Power type and voltage
• AC/DC-set / 110-130 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 2.4 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: BF-162 - Iberia Radio, S.A.; Barcelona

• Shape
• Tablemodel with Push Buttons.

• Literature/Schematics (1)
• Manufacturer Service Manual

• Author
• Model page created by Ramon Gancedo. See "Data change" for further contributors.
