Emperador 744-A Serie S
Iberia Radio SA; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Iberia Radio SA; Barcelona
- Year
- 1946
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 106487
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Emperador 744-A Serie S - Iberia Radio SA; Barcelona
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Iberia Radio, S.A., Emperador
Mando Kronex de banda elástica automática (anuncio)
- Mentioned in
- Anuncio La Vanguardia Española febrero 1946
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Jose Antonio Gonzalez-Ruiz. See "Data change" for further contributors.
