• Country
• Spain

• Manufacturer / Brand
• Iberia Radio, S.A.; Barcelona

• Year
• 1950/1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 95290

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECH42 ECH42 EAF42 EAF42 EL41 AZ41

• Main principle
• Superhet, double/triple conversion; ZF/IF 472 kHz; 2 AF stage(s)

• Tuned circuits
• 8 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: H-8651 - Iberia Radio, S.A.; Barcelona

• Shape
• Tablemodel, low profile (big size).

• Notes

• Iberia Radio, S.A., H-8651

  Superheterodino de doble conversión

  Primera F.I. variable de 2,75 a 3,25 Mc.
  First IF variable between 2.75 and 3.25 MHz.

  Single conversion and 6 tuned circuits for MW.

• Price in first year of sale
• 3,349.05 Pts

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
