• Country
• Spain

• Manufacturer / Brand
• Iberia Radio, S.A.; Barcelona

• Year
• 1962 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 112496

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors
• AF124 AF125 AF125 AF126 AF126 SFD107 AF126 SFD107 1N542 1N542 AC126 AC126 AC128 AC128

• Main principle
• Superheterodyne (common); ZF/IF 450 kHz; 3 AF stage(s)

• Tuned circuits
• 2 AM circuit(s)     1 FM circuit(s)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 125; 220 / 6 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 inch = 11.4 cm

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: TS-4105 - Iberia Radio, S.A.; Barcelona

• Notes
• 1N542 and SFD107 reemplazable por /replaced by OA79

• Literature/Schematics (1)
• Manufacturer Service Manual

• Author
• Model page created by Ramon Gancedo. See "Data change" for further contributors.
