- Country
- Japan
- Manufacturer / Brand
- Icom, Inoue Communication Equipment Corp.; Osaka
- Year
- 1985 ??
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 75479
-
- alternative name: INOUE COMM. E. CORP
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 13.8 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: IC-28A - Icom, Inoue Communication
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 137 x 50 x 130 mm / 5.4 x 2 x 5.1 inch
- Notes
- ICOM Mobile-VHF-FM-Transceiver IC-28A.
Range: TX 140.1-150 MHz, RX 138-174 MHz (5/10/15/20/25 kHz steps); 21 memories; Pout: 25 W/5 W.
- Net weight (2.2 lb = 1 kg)
- 1.3 kg / 2 lb 13.8 oz (2.863 lb)
- Author
- Model page created by Iven Müller. See "Data change" for further contributors.
