IC-703

Icom, Inoue Communication Equipment Corp.; Osaka

Data
Forum
Pictures
Collections

  • Year
  • 2003
  • Category
  • Amateur TRX: Transmitter/Receiver (and Transceiver)
  • Radiomuseum.org ID
  • 177086
    • alternative name: INOUE COMM. E. CORP

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superhet, double/triple conversion; ZF/IF 64455/455 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Powered by external power supply or a main unit. / DC 13,8 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 1 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: IC-703 - Icom, Inoue Communication
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 167 x 58 x 200 mm / 6.6 x 2.3 x 7.9 inch
  • Notes
  • Icom KW-/50-MHz-QRP-Transceiver IC-703.
    Frequenzbereiche TX: alle KW-Amateurfunkbänder von 160-10 m und 50-52 MHz, RX: 0,03...60 MHz; Betriebsarten: SSB, AM, CW, RTTY, FM; Pout: 0,1...10 W (AM 0,1...4 W).
    DSP-Einheit; Bandscope-Funktion; ZF-Shift-Funktion; RIT; automatischer Antennentuner mit Latch-Relais; Sprachprozessor; elektronischer Speicherkeyer; 105 Speicher; Stromaufnahme bei Senden 3 A, bei Empfang 1,2 A.
  • Net weight (2.2 lb = 1 kg)
  • 2 kg / 4 lb 6.5 oz (4.405 lb)
  • Price in first year of sale
  • 969.00 EUR
  • Mentioned in
  • FA 6/03
  • Author
  • Model page created by Bernd P. Kieck. See "Data change" for further contributors.
