- Country
- Japan
- Manufacturer / Brand
- Icom, Inoue Communication Equipment Corp.; Osaka
- Year
- 1991
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 188293
-
- alternative name: INOUE COMM. E. CORP
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet, double/triple conversion; ZF/IF 70450/9010/455 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Powered by external power supply or a main unit. / 13.8 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: IC-726 - Icom, Inoue Communication
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 241 x 94 x 239 mm / 9.5 x 3.7 x 9.4 inch
- Notes
- ICOM KW-Transceiver IC-726.
Frequenzbereiche RX: 100 kHz bis 30 MHz und 54–56 MHz, TX: 160–10 m einschl. WARC-Bänder sowie 50–54 MHz; Betriebsarten: SSB, AM, CW; Pout: 100 W auf KW, 10 W auf 50 MHz (AM 40 bzw. 4 W).
26 Speicher; Stromaufnahme: max. 20 A.
- Net weight (2.2 lb = 1 kg)
- 4.8 kg / 10 lb 9.2 oz (10.573 lb)
- Price in first year of sale
- 2,480.00 DM
- Mentioned in
- beam Amateurfunk-Geräteführer '92
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
