- Country
- Japan
- Manufacturer / Brand
- Icom, Inoue Communication Equipment Corp.; Osaka
- Year
- 1994
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 139187
-
- alternative name: INOUE COMM. E. CORP
FA 7/94
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet, double/triple conversion
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 187-265 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.6 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: IC-736 - Icom, Inoue Communication
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 330 x 111 x 285 mm / 13 x 4.4 x 11.2 inch
- Notes
- ICOM HF-/VHF-Transceiver IC-736.
Frequenzbereich: TX Amateurfunkbänder 160-6 m inkl. WARC, RX 0.03-30 MHz und 45-60 MHz; Zwischenfrequenzen: 1. ZF 69,0105 MHz (AM, FM), 69,0115 MHz (SSB); 2. ZF 9,0105 MHz (AM, FM), 9.0115 MHz (SSB); 3. ZF 455 kHz. Eingebauter Antennentuner, ZF-Verschiebung PBT, Störaustaster, Vorverstärker/Abschwächer, 2 VFOs für Split-Betrieb, 2 Antennenanschlüsse, eingebauter Keyer, Sprachkompressor; Pout: 100 W (AM 40 W).
- Net weight (2.2 lb = 1 kg)
- 10.5 kg / 23 lb 2 oz (23.128 lb)
- Price in first year of sale
- 5,000.00 DM
- Mentioned in
- FA 7/94
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
