Transceiver IC-210

Icom, Inoue Communication Equipment Corp.; Osaka

Data
Forum
Pictures
Collections

  • Year
  • 1975 ??
  • Category
  • Commercial Transmitter & Receiver (TRX not Amateur)
  • Radiomuseum.org ID
  • 336829
    • alternative name: INOUE COMM. E. CORP

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Transceiver
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / AC: 220 / DC: 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Transceiver IC-210 - Icom, Inoue Communication
  • Notes

  • Base station with power from 0.5 to 10 Watt. It operates in the 144 - 146 MHz range in FM, all VFO with the possibility of release bridges at 600 kHz.
    Can operate in simplex or duplex mode.
    SWR/RF meter.

  • Mentioned in
  • -- Original prospect or advert (“Radio Rivista” official organ of "ARI Amateur Radio Association" of Italy, number 7, May 1975.)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
