- Country
- Germany
- Manufacturer / Brand
- Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen
- Year
- 1971–1973
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 116475
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Number of Transistors
- 15
- Semiconductors
- AF279 AF280 AF239 AF106 AF106 BF196 BF173 BF173 BC107 BF258 BC107 BF120 2N5086 2N3855 BC174 TAA550 TAA790 TBA120 B30C150 BB105 BA182 BAY19 BY127 E30C120 OA90 OA91 SFC-5.5MA ZF12 ZG8,2 1N4148
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: FT454 Ch= M100 - Imperial Rundfunk und Fernseh
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 720 x 500 x 370 mm / 28.3 x 19.7 x 14.6 inch
- Notes
-
VHF/UHF-Kombituner mit Diodenabstimmung.
- Net weight (2.2 lb = 1 kg)
- 35 kg / 77 lb 1.5 oz (77.093 lb)
- Source of data
- Handbuch VDRG 1971/1972
- Mentioned in
- - - Manufacturers Literature
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
