- Country
- Germany
- Manufacturer / Brand
- Imperial Rundfunk und Fernseh (Kuba-Imperial, auch General Electric); Osterode/Harz, Hemmingen
- Year
- 1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 109584
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
- Loudspeaker
- 3 Loudspeakers
- Power out
- 5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: J407W - Imperial Rundfunk und Fernseh
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 675 x 365 x 270 mm / 26.6 x 14.4 x 10.6 inch
- Notes
- Zwei permanentdynamische Ovallautsprecher 250×130 mm, ein Elektrostat (LSH75).
- Net weight (2.2 lb = 1 kg)
- 12 kg / 26 lb 6.9 oz (26.432 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Ekkehard Pfau. See "Data change" for further contributors.
