Magnetofón de hilo AM-50 (2ª versión) 2 cabezales
Ingra; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Ingra; Barcelona
- Year
- 1950 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 321917
- Number of Tubes
- 5
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Wire Recorder (or -Player)
- Power type and voltage
- Alternating Current supply (AC) / 125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 14 cm = 5.5 inch
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Magnetofón de hilo AM-50 [2 cabezales] - Ingra; Barcelona
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 380 x 210 x 410 mm / 15 x 8.3 x 16.1 inch
- Notes
-
Ingra, Industria de Grabación y Reproducción Acústica, Magnetófono de hilo M-50
Segundo modelo fabricado por Ingra, similar al M-49 pero eliminando del chasis el brazo (pick-up) y la mecánica para reproducción de discos.
El chasis es de fundición de hierro.
- Net weight (2.2 lb = 1 kg)
- 14 kg / 30 lb 13.4 oz (30.837 lb)
- Author
- Model page created by Joan lluis Madrenas-Palou. See "Data change" for further contributors.
