• Country
• Spain

• Manufacturer / Brand
• Ingra; Barcelona

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 199338

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• BC148 BC148 BC148 MC150 BC208 BF194 BF195 BF195 TAA310 TAA611 AA119 SFD112 SZ102

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast only (MW).

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Batteries / addl. power jack / C: 6 x 1,5 / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: RC-200 - Ingra; Barcelona

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 285 x 220 x 75 mm / 11.2 x 8.7 x 3 inch

• Notes

• INGRA (Industria de Grabación y Reproducción Acústica), Radiocassette RC-200

  Véase también Königer 3103

• Net weight (2.2 lb = 1 kg)
• 2.3 kg / 5 lb 1.1 oz (5.066 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
