RC-250
Ingra; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Ingra; Barcelona
- Year
- 1971 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 200194
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 18
- Semiconductors
- AC180 AC181 AC187 BC108 BC109 BF194 or. SF115 BF195 or. SF115 2N3794 2N4288 OA90 SD500 SFD112 SZ6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Batteries / addl. power jack / C: 6 x 1,5 / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RC-250 - Ingra; Barcelona
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
Ingra, Industria de Grabación y Reproducción Acústica, RC-250
Listado un único semiconductor por tipo.
- Net weight (2.2 lb = 1 kg)
- 2.6 kg / 5 lb 11.6 oz (5.727 lb)
- Mentioned in
- Catálogo Ingra 1971
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
