• Country
• Spain

• Manufacturer / Brand
• IREG; Instrumentos Radio Electrónicos Gixá; Barcelona

• Year
• 1958

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 191784

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• ECC40 ECC40

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 125 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Voltimetro Electronico GX-62 - IREG; Instrumentos Radio

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 178 x 250 x 155 mm / 7 x 9.8 x 6.1 inch

• Notes
• cc/ca de 0,1 a 1000 V;R de 0,1 Ohm a 1000 MOhm ; DB de -25 a +55 dB.

• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 2,530.00 Ptas

• Mentioned in
• Revista Española de Electronica Nº 46 de 1958

• Author
• Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
