- Country
- Spain
- Manufacturer / Brand
- Inter Electrónica, S.A., Inter-Grundig, S.A.; Barcelona
- Year
- 1976 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 323142
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 7
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 110; 220 / 6 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: CP-438 - Inter Electrónica, S.A., Inter
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
Como amplificador de audio puede incorporar el circuito integrado TDA1045 o el TAA611, con pequelas modificaciones en sus componentes asociados.
- Mentioned in
- -- Original-techn. papers. (Esquemario de Magnetófonos y cassettes IV 1977)
- Author
- Model page created by Toni Gutiérrez García. See "Data change" for further contributors.
