• Country
• United States of America (USA)

• Manufacturer / Brand
• International Radio Corp (Kadette); Ann Arbor, MI.

• Year
• 1936

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 45022

• • alternative name: International All Wave || International Industries || International Kadette || IRC

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 1C6 34 25S 950

• Main principle
• Superheterodyne (common); ZF/IF 448 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Storage and/or dry batteries / 3 × 1,5 & 3 × 45 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.6 inch = 16.8 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Kadette 400 - International Radio Corp

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 16 x 10.75 x 7 inch / 406 x 273 x 178 mm

• Notes
• SW: 1500 - 4300 kHz.

• Net weight (2.2 lb = 1 kg)
• 15 lb (15 lb 0 oz) / 6.810 kg

• Price in first year of sale
• 30.00 $

• External source of data
• Ernst Erb

• Source of data
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Circuit diagram reference
• Rider's Perpetual, Volume 7 = 1936 and before

• Mentioned in
• Table Top Radios Vol. 1 Stein 98

• Other Models

• Here you find 194 models, 89 with images and 148 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
