• Country
• United States of America (USA)

• Manufacturer / Brand
• International Radio Corp (Kadette); Ann Arbor, MI.

• Year
• 1933

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 45098

• • alternative name: International All Wave || International Industries || International Kadette || IRC

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• 6F7 12A7

• Main principle
• TRF without regeneration

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 100-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Kadette F Jr. - International Radio Corp

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 110 x 160 x 80 mm / 4.3 x 6.3 x 3.1 inch

• Notes
• Resistance line cord; Rider´s shows four different circuits.
  Colors: brown bakelite, brown speckle marble, brown blotch marble, red plascon

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• External source of data
• Ernst Erb

• Source of data
• A Flick of the Switch 1930-1950

• Circuit diagram reference
• Rider's Perpetual, Volume 4 = ca. 1934 and before

• Mentioned in
• Table Top Radios Vol. 1 Stein 98 (Plastic Radios; Stein, 2006)
