- Country
- Spain
- Manufacturer / Brand
- Inter Electrónica, S.A., Inter-Grundig, S.A.; Barcelona
- Year
- 1963 ??
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 315262
todocoleccion.net 188714998 montegordo
todocoleccion.net 188714998 montegordo
todocoleccion.net 188714998 montegordo
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 17
- Valves / Tubes
- PCC189 PCF86 EF80 EF80 EF80 PCL84 PABC80 PCL85 PCF80 PL36 PY81 DY86 12ET1 EF80 PABC80 PCL82 AW47-91 ORP60
- Number of Transistors
- Semiconductors
- OA73
- Main principle
- Superhet with RF-stage; ZF/IF 38900 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: TV-260-B - Inter Electrónica, S.A., Inter
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Inter Electrónica, S.A. TV-260-B
TV B/N de 19" con selector rotativo de VHF tipo Inter 43.09
Altavoz elíptico de 5" x 7"
- Mentioned in
- Esquemario TV REDE, Tomo I, 1964
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
