• Year
  • 1973 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 321063

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • 14
  • Main principle
  • Superhet with RF-stage; ZF/IF 38900 kHz
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 127; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • from Radiomuseum.org
  • Model: TV-355-B [1ª versión] - Inter Electrónica, S.A., Inter
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Inter Electrónica, S.A., TV-355-B

    TV B/N con selector rotativo de VHF y sintonizador para UHF, ambos transistorizados

    Altavoz elíptico de 5" x 7" @ 4 Ω

    Véase también mismo modelo con variaciones en esquema

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
