- Country
- Spain
- Manufacturer / Brand
- Inter Electrónica, S.A., Inter-Grundig, S.A.; Barcelona
- Year
- 1975 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 321738
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- unknown_CRT
- Number of Transistors
- 19
- Main principle
- Superhet with RF-stage; ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / 127; 220 / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: TV-407 - Inter Electrónica, S.A., Inter
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 445 x 330 x 300 mm / 17.5 x 13 x 11.8 inch
- Notes
-
Inter Electrónica, S.A., TV-407
TV B/N 17"
- Sintonizador de VHF/UHF a varicaps, Fagor SCF-27 o similar.
- Seis canales presintonizados seleccionables por sensores capacitivos.
- Altavoz elíptico de 4" x 6".
Colores: Blanco o Negro
Conmutador Alimentación/Carga para la toma de la batería exterior
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
