6623-L

• Country
• Spain

• Manufacturer / Brand
• Invicta Radio, Barcelona

• Year
• 1967

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 204136

• • alternative name: Establecimientos Lucarda || Radio Lucarda, S.L

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• PC900 PCF801 EF183 EF183 EF184 PCL84 ECH84 EF80 EF80 PCL86 PCL85 ECH84 PL500 PY88 DY87 A59-11W

• Number of Transistors
• 2

• Semiconductors
• AF139 AF139

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 6623-L - Invicta Radio, Barcelona

• Shape
• Tablemodel, low profile (big size).

• Notes

• Invicta Radio, televisor 6623-L

  TV B/N 23"
  Selector rotativo de VHF y sintonizador transistorizado de UHF

  Posiblemente este modelo sea el mismo que el 6623 de Luxe Botonera de Oro, de manera que la propaganda lo anuncie como "De Luxe" y en la documentación como "L" (a verificar)
