- Country
- Great Britain (UK)
- Manufacturer / Brand
- Invicta Radio Ltd.; Cambridge, London
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 200609
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and more than two Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: AW57 - Invicta Radio Ltd.; Cambridge,
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Triple gang Tuning to add extra Bandpass/Aerial RF tuning, though no RF preamp. Similar but not indentical chassis used on some Lissen, Ever Ready and Pye Models (all Pye metal work).
- Price in first year of sale
- 19.95 GBP
- Literature/Schematics (1)
- Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (152)
- Author
- Model page created by Howard Craven. See "Data change" for further contributors.
