Trovador Supertone 751
IRE (Industrias Radioeléctricas, Sdad. Ltda.); Vigo (Pontevedra)
- Country
- Spain
- Manufacturer / Brand
- IRE (Industrias Radioeléctricas, Sdad. Ltda.); Vigo (Pontevedra)
- Year
- 1945 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 320253
Front as-is
Detail original knob.
Double glass for dial.
TOP of the radio
original rear showing all american tubes.
- Number of Tubes
- 0
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
- Power out
- 3 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Trovador Supertone 751 - IRE Industrias Radioeléctricas
- Shape
- Design Radio or Novelty / Gadget - fancy or unusual shape.
- Dimensions (WHD)
- 450 x 350 x 250 mm / 17.7 x 13.8 x 9.8 inch
- Notes
-
IRE (Industrias Radioeléctricas, S. L.), Supertone-751, modelo Trovador
- Author
- Model page created by Carlos Insa Gracia. See "Data change" for further contributors.
- Other Models
-
Here you find 2 models, 2 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from IRE (Industrias Radioeléctricas, Sdad. Ltda.); Vigo (Pontevedra)
Collections
The model Trovador is part of the collections of the following members.
