• Country
• Italy

• Manufacturer / Brand
• Irradio; Milano

• Year
• 1948 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 126619

• Number of Tubes
• 6

• Valves / Tubes
• 6TE8 6K7 6Q7 6L6 6E5 5Y3

• Main principle
• Superheterodyne (common); ZF/IF 467 kHz; 1 AF stage(s)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110-220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 23.5 cm = 9.3 inch

• Power out
• 4 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: EL38 - Irradio; Milano

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 680 x 350 x 250 mm / 26.8 x 13.8 x 9.8 inch

• Notes
• Ricevitore con 1 Gamma OM e n.3 gamme OC + Fono. Altoparlante della IREL modello Cambridge.

• Mentioned in
• -- Collector info (Sammler)

• Author
• Model page created by Salvatore Baldi † 2017. See "Data change" for further contributors.
