Digital Multitester DM 3500
ISI Teston; Ishii Instrument Works; Yamanashi
- Country
- Japan
- Manufacturer / Brand
- ISI Teston; Ishii Instrument Works; Yamanashi
- Year
- 1979 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 342025
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / PP3: 1 x 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Digital Multitester DM 3500 - ISI Teston; Ishii Instrument
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 147 x 96 x 46 mm / 5.8 x 3.8 x 1.8 inch
- Notes
-
3-½ digit, 7 segment Liquid Crystal Display
- Net weight (2.2 lb = 1 kg)
- 0.260 kg / 0 lb 9.2 oz (0.573 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
