RCL Merilnik - RLC Bridge MA 4300

Iskra; Kranj, Ljubljana

Data
Forum
Pictures
Collections

  • Year
  • 1960 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 234321

 Technical Specifications

  • Number of Tubes
  • 2
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: RCL Merilnik - RLC Bridge MA 4300 - Iskra; Kranj, Ljubljana
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 262 x 200 x 144 mm / 10.3 x 7.9 x 5.7 inch
  • Notes

  • Tube operated RCL bridge.

    Measuring ranges:

    R: 10Ohm - 10 MOhm

    C: 10pF - 10uF

    L: 10mH - 10H

    Measuring voltages 5V and 20V

  • Net weight (2.2 lb = 1 kg)
  • 4.5 kg / 9 lb 14.6 oz (9.912 lb)
  • Author
  • Model page created by Vladimir Markovic. See "Data change" for further contributors.
