Kompaktbox Isonetta
Isophon, E. Fritz & Co. GmbH.; Berlin
- Country
- Germany
- Manufacturer / Brand
- Isophon, E. Fritz & Co. GmbH.; Berlin
- Year
- 1971–1975
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 165307
-
- Brand: Isophon
Isophon Sales Brochure
Isophon Sales Brochure
Isophon Sales Brochure
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 cm = 2.6 inch
- Power out
- 5 W (8 W max.)
- Material
- Bakelite or Plastics (type unknown)
- from Radiomuseum.org
- Model: Kompaktbox Isonetta - Isophon, E. Fritz & Co. GmbH.;
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 110 x 90 x 75 mm / 4.3 x 3.5 x 3 inch
- Notes
-
Breitbandlautsprecher in Kugelform. Kunststoffgehäuse, nicht zerlegbar, temperaturbeständig bis +100 °C (für den Einsatz im Auto). Lautsprecher ø 65 mm, Übertragungsbereich 200 bis 20.000 Hz, Impedanz 5 Ω.
Lieferbar in orange, schwarz, rot und weiß.
- Net weight (2.2 lb = 1 kg)
- 0.350 kg / 0 lb 12.3 oz (0.771 lb)
- Price in first year of sale
- 48.00 DM
- Mentioned in
- Isophon Katalogblatt 1971, Preisliste 1971
- Author
- Model page created by Hans-Werner Ellerbrock. See "Data change" for further contributors.
