• Country
• Italy

• Manufacturer / Brand
• ITT Italy; Vimercate

• Year
• 1985 ?

• Category
• Miscellaneous (Other, Various) - see notes

• Radiomuseum.org ID
• 187577

• Number of Transistors
• 4

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 2 x 1,5 & 3 x 6 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Pocketmeter 3301 - ITT Italy; Vimercate

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 185 x 38 x 122 mm / 7.3 x 1.5 x 4.8 inch

• Notes
• 20.000 Ohm/V in c.c.
  6.300 Ohm/V in c.a.
  tensione in c.c. 0,1-0,5-1,5-5-15-50-150-500-1.500 V
  tensione in c.a. 1,5-5-15-50-150-500-1500 V
  corrente in c.c. 50 µA - 0,5-5-50 mA - 0,5-5 A
  corrente in c.a. 150 µA - 1,5-15-150 mA - 1,5-5 A
  Ohm x1 - x10 - x100 - x1.000 - x10.000 fondo scala 2 kOhm
  Low Ohm 200 Ohm fondo scala.

• Net weight (2.2 lb = 1 kg)
• 0.580 kg / 1 lb 4.4 oz (1.278 lb)

• Source of data
• - - Data from my own collection

• Author
• Model page created by Biagio Laureti. See "Data change" for further contributors.
