Tiny 503L 5510 83 10
ITT Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- ITT Schaub-Lorenz
- Year
- 1987–1989 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 262429
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave and FM or UHF.
- Power type and voltage
- Line / Batteries (any type) / 220 / LR14: 3 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Tiny 503L 5510 83 10 - ITT Schaub-Lorenz
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 220 x 130 x 40 mm / 8.7 x 5.1 x 1.6 inch
- Notes
-
Siehe auch Tiny 503
- Net weight (2.2 lb = 1 kg)
- 0.630 kg / 1 lb 6.2 oz (1.388 lb)
- Author
- Model page created by Holger Struthoff. See "Data change" for further contributors.
