Touring Europa S 52150195 (weinrot)
ITT Schaub-Lorenz
- Country
- Germany
- Manufacturer / Brand
- ITT Schaub-Lorenz
- Year
- 1969–1971
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 75095
Handbuch RFP 1969/70 S.345
Bild aus Prospekt
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 3 AF stage(s)
- Tuned circuits
- 7 AM circuit(s) 13 FM circuit(s)
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Power type and voltage
- Batteries / addl. power jack / D: 5 x 1.5 / 7.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Touring Europa S 52150195 - ITT Schaub-Lorenz
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 300 x 188 x 93 mm / 11.8 x 7.4 x 3.7 inch
- Notes
-
Halbleiter teils mehrfach vorhanden
UKW: 87,0 - 104 MHz
KW: 5800 - 16000 kHz (49m)
MW: 510 - 1620 kHz
LW: 145 - 300 kHzAnschlussbuchse für Netzanschlussgerät NG1001, NG2001 oder Touroclock.
4 Farben: 521501-91 = Dekor Nußbaum, 521501-93 = schwarz, 521501-95 = weinrot, 521501-97 = Dekor Teak. Autohalterungsanschluss. Wir listen alle vier Modelle, da vier verschiedene Typenbezeichnungen vorkommen. Bilder bitte auf das entsprechende Modell (Farbe) laden. Danke.
Preis 1970/71 DM 298,--
- Net weight (2.2 lb = 1 kg)
- 3.4 kg / 7 lb 7.8 oz (7.489 lb)
- Price in first year of sale
- 279.00 DM
- Source of data
- Radiokatalog Band 2, Ernst Erb
- Mentioned in
- Handbuch RFP 1969/70 S.345 (Thiele, Helmstedt)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- Handbuch RFP 1970/71 S.376 (Thiele, Helmstedt)
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
