• Country
• Great Britain (UK)

• Manufacturer / Brand
• ITT-KB; Foots Cray, Kent; (ITT Consumer Products (UK) Ltd. ex Kolster-Brandes)

• Year
• 1969

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 244971

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors
• BC154 BC107 AC128 AC176

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 200-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 3 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: KP049 - ITT-KB; Foots Cray, Kent; ITT

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 452 x 171 x 254 mm / 17.8 x 6.7 x 10 inch

• Notes

• External loudspeaker impedance 15 ohms

• Net weight (2.2 lb = 1 kg)
• 4.5 kg / 9 lb 14.6 oz (9.912 lb)

• Author
• Model page created by Mike Edwards † 25.10.21. See "Data change" for further contributors.
