- Country
- Czechoslovakia
- Manufacturer / Brand
- Jiskra, Výrobní Družstvo Strojníků a Nástrojárů; Pardubice
- Year
- 1960
- Category
- Kit (Parts plus instruction) or building instructions only
- Radiomuseum.org ID
- 132354
- Number of Transistors
- 7
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 452 kHz
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 4 × 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 360 T - Jiskra, Výrobní Družstvo
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 310 x 210 x 150 mm / 12.2 x 8.3 x 5.9 inch
- Notes
- Transistorradio Selbstbausatz 360T; es wurden Muster gebaut und vorgestellt, jedoch kam das Gerät über die Nullserie nicht hinaus. Transistoren: 154NU70, 2× 153NU70, 2 × 102NU70, 2 × 102NU71.
- Source of data
- -- Collector info (Sammler)
- Author
- Model page created by Wolfgang Lill. See "Data change" for further contributors.
