Globe-King S.W. Receiver 100/A
Johnsons (Radio); Worcester
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Johnsons (Radio); Worcester
- Year
- 1960
- Category
- Amateur-Receiver (amateur bands, may include broadcast bands)
- Radiomuseum.org ID
- 204311
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- HL23
- Main principle
- TRF with regeneration
- Tuned circuits
- 1 AM circuit(s)
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage and/or dry batteries / 3 & 90 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Globe-King S.W. Receiver 100/A - Johnsons Radio; Worcester
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 6 x 1.25 x 3.5 inch / 152 x 32 x 89 mm
- Notes
- Kit, sold in assembled form as Globe-King 100/B.
Coils available:
Coil No. 1: 30 - 17.5 MHz
Coil No. 2: 15 - 7.5 MHz
Coil No. 3: 7.3 - 3 MHz.
- Mentioned in
- The Radio Constructor, Sep. 1960 (UK)
