- Country
- Japan
- Manufacturer / Brand
- JVC - Victor Company of Japan, Ltd.; Tokyo
- Year
- 1978
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 149004
Original Prospekt
Original Prospekt
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 96 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: JA-S44 - JVC - Victor Company of Japan,
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 420 x 149 x 317 mm / 16.5 x 5.9 x 12.5 inch
- Notes
-
Stereo Vollverstärker mit integriertem 5-Band-Equalizer.
Sinusleistung von 48 Watt pro Kanal.
2 Wattmeter zum Anzeigen der Ausgangsleistung.Power output: 45 watts per channel into 8Ω (stereo)
Frequency response: 20Hz to 20kHz
Total harmonic distortion: 0.02%
Damping factor: 30
Input sensitivity: 2.5mV (MM), 160mV (DIN), 160mV (line)
Signal to noise ratio: 80dB (MM), 100dB (line)
Output: 160mV (line), 30mV (DIN)
Speaker load impedance: 4Ω to 16Ω
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Source of data
- -- Original prospect or advert
- Mentioned in
- Funkschau (21/1978, S. 1009)
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
