Micro Component System UX-G28

JVC - Victor Company of Japan, Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 2007
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 225404

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • 2 Loudspeakers / Ø 10 cm = 3.9 inch
  • Power out
  • 16 W (undistorted)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Micro Component System UX-G28 - JVC - Victor Company of Japan,
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 144 x 212 x 254 mm / 5.7 x 8.3 x 10 inch
  • Notes

  • The Micro Component System UX-G28 consists of CA-UXG28 (main unit) and SP-UXG28 (speakers).

    • Plays MP3/WMA (CD-R/RW, USB) with Tags
    • 16 W Total Power (8 W x2 / 4 Ohm)
    • Digital Tuner with RDS
    • Clock/Timer
    • USB Host (2.0 Full-Speed)
    • Front Audio Input
    • Headphone connector 3.5 mm
    • 1-bit D/A Converter
    • Hyper-Bass Sound
    • 4 Sound Modes (ROCK/POP/CLASSIC/JAZZ)

    Speaker specifications:

    • 3-15/16" (10cm) Full-Range Bass-Reflex Speakers
    • Impedance 4 Ohms
    • Dimensions (WxHxD): 136 x 212 x 178 mm
    • Weight : 1.3 kg

    Different sub-models exist for 120 and 230 V respectively (UX-G28B, UX-G28E, UX-G28EN, and UX-G28EV).

  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
  • Source of data
  • - - Manufacturers Literature
