Nivico Super Sensitive 10 Transistor Saturn Deluxe 10A-337
JVC - Victor Company of Japan, Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- JVC - Victor Company of Japan, Ltd.; Tokyo
- Year
- 1967–1972
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 319924
- Number of Transistors
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Dry Batteries / D: 3 x 1.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Nivico Super Sensitive 10 Transistor Saturn Deluxe 10A-337 - JVC - Victor Company of Japan,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 9.5 x 5.625 x 2.125 inch / 241 x 143 x 54 mm
- Notes
-
Nivico Model 10A-337
A 10 transistor, 3 band portable. Features low and high tone selector switch, tuning indicator, fine tuning control, ferrite rod aerial for MW. Earphone jack for private listening.
Frequency range: MW, 535 - 1606 kHz; SW1, 2.3 - 6.2 MHz; SW2, 7.1 - 17.9 MHz. (MINGAY'S PRICE SERVICE)
- Net weight (2.2 lb = 1 kg)
- 1 lb 6 oz (1.375 lb) / 0.624 kg
- Price in first year of sale
- 75.75 AUS $
- Mentioned in
- Mingay's Price Service (Aug 1967 to Feb 1972.)
- Literature/Schematics (1)
- J.R. Publications Transistor Radio Service Handbook (Group G7, 1970, Page 229.)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
